Genişletilmiş LCD Ekran

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Tüm Kategori

Geniş ekranlı LCD bilgisayar monitörleri

Medikal LCD Panel

Bizimle İletişim

Mr. pippo tian

pippo@ridafone.com

+86 13590447319

Şimdi iletişime geçin

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Marka Adı:	BOE
Model Numarası:	DV280FBM-NB1
Adedi:	10 adet
fiyat:	negotiable
Paketleme Ayrıntıları:	Endüstriyel paketleme
Ödeme Şartları:	T/T, W, Western Union, MoneyGram

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Sertifika:

Rohs,CE,FCC

Kalite:

Yepyeni Orijinal

Paket:

Orijinal endüstriyel paketleme

Malzeme:

cam led

Renk:

16.7m

Modeli:

LCM, TFT

Stil:

Çubuk LCD Ekran

Çözünürlük:

1920*360 piksel

Parlaklık:

700CCD/M2

Bağlayıcı:

51pin

Çalışma hayatı:

50 bin saat

Kontrast Oranı:

1200:1

Ekran Boyutu:

28 inç

Yetenek temini:

Haftada 3000 pc

Ürün Tanımı

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

DV280FBM-NB1 is a 28.0" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: Hight Brightness, WLED Backlight, Life ≥ 50K hours, Bar Display , 1/3 cut of 31.5". Based on its features, Einklcd recommend that this model be applied to Digital Signage, Outdoor High Brightness, Stretched Bar LCD etc. According to the information stored in einklcd this model mass production on Q1, 2016, Now this model is in production. We inputted this model's specification on May 23 2016 for the first time, and the latest update on Sep 5 2025. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of DV280FBM-NB1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:BOE

Model P/N: DV280FBM-NB1

Diagonal Size 28.0" (1/3 cut of 32.0")

Panel Type: a-Si TFT-LCD, LCM

Resolution1920(RGB)×360 69PPI Pixel

Format RGB Vertical Stripe

Active Area 699.84(W)×131.22(H) mm

Bezel Opening 704(W)×136(H) mm

Outline Size: 732(W)×165(H) ×17.3(D) mm

Brightness:700 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors: 16.7M 72% NTSC

Frequency 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 2.40Kgs (Typ.)

Surface

Contrast Ratio:1200:1 (Typ.) (TM)

Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time :8 (Typ.)(G to G)

Lamp Type: WLED , 50K hours , Without Driver

Touch Screen :Without

Application:Digital Signage Outdoor High Brightness Stretched Bar LCD

Signal Interface LVDS (1 ch, 8-bit) , 51 pins Connector

Input Voltage 12.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C

Etiketler:

çubuk tipi ekran

germe monitörü ekranı

gerilmiş LCD monitörü

Ürün ayrıntıları

Evde > Ürünler >

Genişletilmiş LCD Ekran

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Tüm Kategori

endüstriyel lcd ekran

LCD Dokunmatik Ekran Monitör

Geniş ekranlı LCD bilgisayar monitörleri

PC LCD Modülü

Büyük LCD Ekranı

LCD TV paneli

Genişletilmiş LCD Ekran

Araba LCD ekranı

E Mürekkep Ekran Modülü

E Mürekkep LCD Ekranı

Medikal LCD Panel

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Marka Adı:	BOE
Model Numarası:	DV280FBM-NB1
Adedi:	10 adet
fiyat:	negotiable
Paketleme Ayrıntıları:	Endüstriyel paketleme
Ödeme Şartları:	T/T, W, Western Union, MoneyGram

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

ÇİN

Marka adı:

BOE

Sertifika:

Rohs,CE,FCC

Model numarası:

DV280FBM-NB1

Kalite:

Yepyeni Orijinal

Paket:

Orijinal endüstriyel paketleme

Malzeme:

cam led

Renk:

16.7m

Modeli:

LCM, TFT

Stil:

Çubuk LCD Ekran

Çözünürlük:

1920*360 piksel

Parlaklık:

700CCD/M2

Bağlayıcı:

51pin

Çalışma hayatı:

50 bin saat

Kontrast Oranı:

1200:1

Ekran Boyutu:

28 inç

Min sipariş miktarı:

10 adet

Fiyat:

negotiable

Ambalaj bilgileri:

Endüstriyel paketleme

Teslim süresi:

4-5 iş günü

Ödeme koşulları:

T/T, W, Western Union, MoneyGram

Yetenek temini:

Haftada 3000 pc

Ürün Tanımı

BOE 28inch Stretched LCD Display DV280FBM-NB1 51Pin Monitor 1920*360pixels Outdoor Brightness and Long Working Life

Brand:BOE

Model P/N: DV280FBM-NB1

Diagonal Size 28.0" (1/3 cut of 32.0")

Panel Type: a-Si TFT-LCD, LCM

Resolution1920(RGB)×360 69PPI Pixel

Format RGB Vertical Stripe

Active Area 699.84(W)×131.22(H) mm

Bezel Opening 704(W)×136(H) mm

Outline Size: 732(W)×165(H) ×17.3(D) mm

Brightness:700 cd/m² (Typ.)

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down

Best View on Symmetry

Display Colors: 16.7M 72% NTSC

Frequency 60Hz 120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Weight: 2.40Kgs (Typ.)

Surface

Contrast Ratio:1200:1 (Typ.) (TM)

Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Response Time :8 (Typ.)(G to G)

Lamp Type: WLED , 50K hours , Without Driver

Touch Screen :Without

Application:Digital Signage Outdoor High Brightness Stretched Bar LCD

Signal Interface LVDS (1 ch, 8-bit) , 51 pins Connector

Input Voltage 12.0V (Typ.)

Environment Operating Temp.: 0 ~ 50 °C ;

Storage Temp.: -20 ~ 60 °C
