Genişletilmiş LCD Ekran

BOE 12.6inch Stretched LCD Display with 1920*515pixels Resolution and 157PPI for Laptop Applications

Tüm Kategori

Geniş ekranlı LCD bilgisayar monitörleri

Medikal LCD Panel

Bizimle İletişim

Mr. pippo tian

pippo@ridafone.com

+86 13590447319

Şimdi iletişime geçin

BOE 12.6inch Stretched LCD Display with 1920*515pixels Resolution and 157PPI for Laptop Applications

Marka Adı:	BOE
Model Numarası:	NV126B5M-N42
Adedi:	10 adet
fiyat:	negotiable
Paketleme Ayrıntıları:	Endüstriyel paketleme
Ödeme Şartları:	T/T, W, Western Union, MoneyGram

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Sertifika:

Rohs,CE,FCC

Kalite:

Yepyeni Orijinal

Paket:

Orijinal endüstriyel paketleme

Malzeme:

cam led

Renk:

16.7m

Modeli:

LCM, TFT

Stil:

Çözünürlük:

1920*515PİKSEL

Parlaklık:

400ccd/m2

Bağlayıcı:

30pin

Çalışma hayatı:

15 bin saat

Kontrast Oranı:

1200:1

Ekran Boyutu:

12.6inch

Yetenek temini:

Haftada 3000 pc

Vurgulamak:

12.6inch Stretched LCD Display

1920*515pixels Stretched LCD Display

157PPI Stretched LCD Display

Ürün Tanımı

BOE 12.6inch Stretched LCD Display NV126B5M-N42 51Pin Monitor 1920*515pixels 157PPI stretched lcd panel laptop lcd model

BOE Technology Group Co., Ltd. (hereafter called BOE) NV126B5M-N42 (Product Code: BOE0921) is a 12.6 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 60°C , a storage temperature range of -20 ~ 65°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: WLED Backlight, With LED Driver, Bar Display, Matte , eDP1.2, sDRRS, CABC, for Asus. Based on its features, einklcd recommend that this model be applied to Laptop, Stretched Bar LCD etc. According to the information stored in einklcd this model mass production on Q1, 2021, Now this model is in production. We inputted this model's specification on Dec 29 2020 for the first time, and the latest update on Jan 24 2025. If you want to embed NV126B5M-N42 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's distributor to learn lateast production and specification detail. The NV126B5M-N42 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

Brand:BOE

Model P/N:NV126B5M-N42

Diagonal Size: 12.6"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 1920(RGB)×515 157PPI

Pixel Format:RGB Vertical Stripe

Active Area 309.312(W)×82.9665(H) mm

Bezel Opening-

Outline Size: 315.61(W)×94.02(H) ×5(D) mm

Surface Antiglare (Haze 40%), Hard coating

Brightness: 400 cd/m² (Typ.)

Contrast Ratio 1200:1 (Typ.) (TM)

Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down Display Mode ADS, Normally Black, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Best View on Symmetry

Response Time: 30 (Typ.)(Tr+Td)

Display Colors :16.7M 45% NTSC

Lamp Type 8S6P WLED , 15K hours , With LED Driver

Frequency: 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Screen:Without

Shape Style -

Application : Laptop Stretched Bar LCD

Signal Interface : eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector

Input Voltage 3.3V (Typ.)

Environment Operating Temp.: 0 ~ 60 °C ;

Storage Temp.: -20 ~ 65 °C

Etiketler:

çubuk tipi ekran

germe monitörü ekranı

gerilmiş LCD monitörü

Ürün ayrıntıları

Evde > Ürünler >

Genişletilmiş LCD Ekran

BOE 12.6inch Stretched LCD Display with 1920*515pixels Resolution and 157PPI for Laptop Applications

Tüm Kategori

endüstriyel lcd ekran

LCD Dokunmatik Ekran Monitör

Geniş ekranlı LCD bilgisayar monitörleri

PC LCD Modülü

Büyük LCD Ekranı

LCD TV paneli

Genişletilmiş LCD Ekran

Araba LCD ekranı

E Mürekkep Ekran Modülü

E Mürekkep LCD Ekranı

Medikal LCD Panel

BOE 12.6inch Stretched LCD Display with 1920*515pixels Resolution and 157PPI for Laptop Applications

Marka Adı:	BOE
Model Numarası:	NV126B5M-N42
Adedi:	10 adet
fiyat:	negotiable
Paketleme Ayrıntıları:	Endüstriyel paketleme
Ödeme Şartları:	T/T, W, Western Union, MoneyGram

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Çin

Marka adı:

BOE

Sertifika:

Rohs,CE,FCC

Model numarası:

NV126B5M-N42

Kalite:

Yepyeni Orijinal

Paket:

Orijinal endüstriyel paketleme

Malzeme:

cam led

Renk:

16.7m

Modeli:

LCM, TFT

Stil:

Lcm

Çözünürlük:

1920*515PİKSEL

Parlaklık:

400ccd/m2

Bağlayıcı:

30pin

Çalışma hayatı:

15 bin saat

Kontrast Oranı:

1200:1

Ekran Boyutu:

12.6inch

Min sipariş miktarı:

10 adet

Fiyat:

negotiable

Ambalaj bilgileri:

Endüstriyel paketleme

Teslim süresi:

4-5 iş günü

Ödeme koşulları:

T/T, W, Western Union, MoneyGram

Yetenek temini:

Haftada 3000 pc

Vurgulamak:

12.6inch Stretched LCD Display

1920*515pixels Stretched LCD Display

157PPI Stretched LCD Display

Ürün Tanımı

BOE 12.6inch Stretched LCD Display NV126B5M-N42 51Pin Monitor 1920*515pixels 157PPI stretched lcd panel laptop lcd model

Brand:BOE

Model P/N:NV126B5M-N42

Diagonal Size: 12.6"

Panel Type: a-Si TFT-LCD, LCM

Resolution: 1920(RGB)×515 157PPI

Pixel Format:RGB Vertical Stripe

Active Area 309.312(W)×82.9665(H) mm

Bezel Opening-

Outline Size: 315.61(W)×94.02(H) ×5(D) mm

Surface Antiglare (Haze 40%), Hard coating

Brightness: 400 cd/m² (Typ.)

Contrast Ratio 1200:1 (Typ.) (TM)

Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down Display Mode ADS, Normally Black, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Best View on Symmetry

Response Time: 30 (Typ.)(Tr+Td)

Display Colors :16.7M 45% NTSC

Lamp Type 8S6P WLED , 15K hours , With LED Driver

Frequency: 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit

Touch Screen:Without

Shape Style -

Application : Laptop Stretched Bar LCD

Signal Interface : eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector

Input Voltage 3.3V (Typ.)

Environment Operating Temp.: 0 ~ 60 °C ;

Storage Temp.: -20 ~ 65 °C
